Xiongmai Camera Firmware Backdoor Exploited by LeetHozer IoT Botnet

Vulnerability Disclosure · 6 sources · Updated 3mo ago · First seen Mar 26, 2020

Xiongmai Camera Firmware Backdoor Exploited by LeetHozer IoT Botnet

A backdoor in Xiongmai-based DVRs, NVRs, and IP cameras exposed affected devices to remote takeover by allowing attackers to recover a pre-shared key, authenticate over TCP/9530, and enable telnet access for root-level control. The issue affected products sold under many brands and hundreds of models, particularly devices built on HiSilicon-based hardware running Xiongmai firmware, with Internet-exposed vulnerable systems estimated in the hundreds of thousands to millions. Public reporting said the flaw stemmed from Xiongmai software rather than HiSilicon itself, and warned that patching across the fragmented OEM ecosystem was unreliable.

Researchers later linked active exploitation of the flaw to LeetHozer, a Mirai-like IoT botnet that targeted Xiongmai H.264/H.265 devices by abusing port 9530 to turn on telnet and then logging in with default credentials. Netlab 360 said the malware appeared related to the Moobot ecosystem through shared exploit strings and downloader infrastructure, while using redesigned bot logic, encryption, and C2 communications. Once installed, LeetHozer supported multiple DDoS functions, including tcpraw, icmpecho, and udpplain, showing how a widely deployed firmware backdoor moved quickly from public disclosure to operational botnet abuse.

Do you run this?See affected versions and whether adversaries are exploiting it.
Check your exposure
Event timeline

How this story unfolded

Events from the most recent confirmed update back to the earliest known activity.

7 events · Sep 16, 2015 – Mar 26, 2020
  1. Reported Apr 27, 20207y ago

    Netlab 360 published analysis of the LeetHozer botnet

    Netlab 360 published technical analysis describing LeetHozer as a Mirai-like but distinct botnet family likely related to the Moobot group. The report documented its exploitation of Xiongmai devices via port 9530, default-credential logins, DDoS capabilities, and C2 infrastructure.

    The LeetHozer botnet
  2. Mar 26, 20207y ago

    LeetHozer and moobot_xor shared downloader activity observed

    On the same day LeetHozer activity was first seen, researchers observed LeetHozer samples fetched from /ab/i686 and /ab/i586 and a moobot_xor sample fetched from /ab/arm from the same downloader infrastructure at 185.172.110.224. The overlap supported an assessment that the malware families were likely operated by the same actor or group.

    The LeetHozer botnet
  3. Mar 26, 20207y ago

    Researchers first captured a LeetHozer malware sample

    Netlab 360 captured a suspicious malware sample later named LeetHozer. The sample marked the beginning of observed LeetHozer exploitation activity against Xiongmai H.264 and H.265 devices.

    The LeetHozer botnet
  4. Feb 11, 20207y ago

    moobot_xor observed exploiting the Xiongmai vulnerability

    Researchers observed a moobot_xor variant exploiting the same TCP 9530 vulnerability in Xiongmai devices. This showed active weaponization of the issue shortly after the PoC became public.

    The LeetHozer botnet
  5. Feb 4, 20207y ago

    PoC for Xiongmai DVR backdoor released on GitHub

    A proof of concept for the Xiongmai device vulnerability exposed on TCP port 9530 was released on GitHub. The PoC demonstrated how attackers could trigger telnet on affected DVR, NVR, and IP camera devices.

    Full disclosure: 0day vulnerability (backdoor) in firmware for Xiaongmai-based DVRs, NVRs and IP cameras / Habr
  6. Mar 12, 201710y ago

    Blog post documents enabling telnet on Xiongmai cameras

    A Chinese-language blog post documented how telnet could be enabled on Xiongmai cameras, showing public knowledge of the device access mechanism years before the 2020 GitHub PoC and later botnet exploitation. The post focused on research into Xiongmai camera telnet activation.

    雄迈摄像头研究笔记一:telnet的开启 - mmseh - 博客园
  7. Sep 16, 201511y ago

    Xiongmai issues security advisory for vulnerable XM products

    Hangzhou Xiongmai Technology published a security advisory addressing vulnerabilities affecting some XM products. The advisory predates the 2017 public blog documentation and later 2020 PoC and botnet exploitation activity already captured in the timeline.

    Hangzhou Xiongmai Technology Co.,LTD.-Security Advisory - Vulnerability of some XM product before year 2017
